FMSRS Motorized Stages on a Curved Rail



The FMSRS motorized stages on a Curved Rail uses arc linear motor, high precision arc guide rail, and adopts high quality grating ruler as feedback, so as to realize rotation movement in a certain Angle.



Range of angular rotation：60°；

High quality grating ruler feedback：Resolution up to 0.001°；

Professional control software;

Free standard edition SDK：Multiple development languages are supported in the Window or Linux environment；Such as C/C++、C#、Matlab、LabVIEW etc；

The controller：Realize arc interpolation, linear interpolation, position memory to lead into arbitrary-graphics；

Option:Bus control of EtherCAT



APPLICATION  FIELDS



Optical Path Switching 、Industrial CT 、Semiconductor Inspection 、Machine Vision 、Medical Beauty

Product parameters

Model

FMSRS300-60

Travel(°)

60

Load Capacity(Kg)[1]

10

Resolution(°)

0.001

Min.Incremental Motion(°)[2]

0.002

Undirection Repeatability[3]/Guaranteed(°)[4]

±0.005 or 0.01

Undirection Repeatability/Typical(°)

±0.003 or 0.006

Bi-Directional Repeatability/Guaranteed(°)

±0.01 or 0.02

Bi-Directional Repeatability/Typical(°)

±0.02 or 0.04

Accuracy[3]/Guaranteed(°)

±0.02 or 0.04

Accuracy/Typical(°)

±0.03 or 0.06

Max.Speed(°/s)[5]

10

Flatness(μm)

15

Yaw(arcsec)

15

Pitch(arcsec)

15

Weight(kg)

14.5



Remark：

[1]：The vertical-load of the center under the Horizontal-placement。

[2]：The  minimum motion increment is not the same as resolution,It means the minimum amount that a motion system can move in a continuous, stable situation. Generally, The resolution of the system is much smaller than the minimum motion increment. In consideration of the influence of transmission structure and the system error of the encoder, To compared with the linear motor Motorized drive Stages and the stepping motor Motorized drive Stages, The minimum motion increment of the linear motor Motorized drive Stages is more closer to the resolution.

[3]：The accuracy measurement data is the data measured by the laser interferometer when the platform is placed horizontally. The measurement standard reference to GB/T17421-2000

[4]：The difference between typical values and guaranteed values is described in the Technical Guide.

[5]：The maximum speed is typical values , on the basis of the difference of the load and the controller it would be Make a difference.

Product size
