FMSR100V Vacuum Stepping Motor Rotary Stage

$3760 Delivery date：3-4 weeks

Model:

Product Consultation

Scan the QR code for consultation

Or make a phone call：

028-8586 4663

Send email：

info@feinixs.com
Product Details

FMSR100V Vacuum Stepping Motor Rotary Stage



The Feinixs FMSR100V Vacuum Stepping Motor Rotary Stage is specifically designed for applications requiring precise angular positioning in a vacuum environment. The FMSR100V vacuum rotary stage uses a vacuum-specific motor and a stainless steel body, ensuring a high vacuum level. It also features high precision, high stability, and other characteristics. Its modular design makes it easy to integrate with other Feinixs products to build multi-dimensional displacement platforms, meeting diverse application needs.



Vacuum Environment, Stable and Reliable: Employing special materials and vacuum-compatible design, it can operate stably for extended periods in a vacuum environment ranging from 10⁻⁷ Pa to 10⁻³ Pa.

Extreme Temperature Tolerance, Consistent Performance: Maintains high precision and stability even within an extreme temperature range of -196°C to +250°C.

Stainless Steel Material, Robust and Durable: Constructed with stainless steel, offering corrosion resistance, oxidation resistance, and robustness. It ensures reliable XY axis assembly with a maximum travel of 50mm x 50mm.

Powerful Software Support, Easy Control: Free standard SDK supports multiple development languages (C/C++, C#, Matlab, LabVIEW, etc.) under Windows and Linux environments, facilitating secondary development and system integration for users.



APPLICATION  FIELDS



Argument Test, Demo Experiment, High-end Teaching Experiment, Ordinary Experimental Equipment

Product parameters

Model

FMSR100V

Travel(°)

360

Load Capacity(Kg)[1]

25

Resolution(°)

0.0025

Min.Incremental Motion(°)[2]

0.01

Undirection Repeatability[3]/Guaranteed(°)[4]

±0.005 or 0.01

Undirection Repeatability/Typical(°)

±0.003 or 0.006

Bi-Directional Repeatability/Guaranteed(°)

±0.01 or 0.02

Bi-Directional Repeatability/Typical(°)

±0.005 or 0.01

Accuracy[3]/Guaranteed(°)

±0.05 or 0.1

Accuracy/Typical(°)

±0.03 or 0.06

Max.Speed(°/s)[5]

20

Face Runout/Guaranteed(μm)

25

Radial Runout/Guaranteed(μm)

25

Weight(kg)

5.9



Remark：

[1]：The vertical-load of the center under the Horizontal-placement。

[2]：The  minimum motion increment is not the same as resolution,It means the minimum amount that a motion system can move in a continuous, stable situation. Generally, The resolution of the system is much smaller than the minimum motion increment. In consideration of the influence of transmission structure and the system error of the encoder, To compared with the linear motor displacement Stages and the stepping motor displacement Stages, The minimum motion increment of the linear motor displacement Stages is more closer to the resolution.

[3]：The accuracy measurement data is the data measured by the laser interferometer when the platform is placed horizontally. The measurement standard reference to GB/T17421-2000

[4]：The difference between typical values and guaranteed values is described in the Technical Guide.

[5]：The maximum speed is typical values , On the basis of the difference of the load and the controller it would be Make a difference.

Product size
